Signature Based Detection of User Events for Post-Mortem Forensic Analysis

As seen on DigitalFIRE

The concept of signatures is used in many fields, normally for the detection of some sort of pattern. For example, antivirus and network intrusion detection systems sometimes implement signature matching to attempt to differentiate legitimate code or network traffic from malicious data. The principle of these systems that that within a given set of data, malicious data will have some recognizable pattern. If malicious code, for example, has a pattern that is different in some way to non-malicious data, then the malicious data may be able to be differentiated with signature-based methods. In terms of malware, however, signature based methods are becoming less effective as malicious software gains the ability to alter or hide malicious patterns. For example, polymorphic or encrypted code.

This work suggests that signature based methods may also be used to detect patterns or user actions of a digital system. This is based on the principle that computer systems are interactive. This means that when a user interacts with the system, the system is immediately updated. In this work, we analyzed a user's actions in relation to timestamp updates on the system.

During experimentation, we found that timestamps on a system may be updated for many different reasons. Our work, however, determined that there are at least three major timestamp update patterns given a user action. We define these as Core, Supporting and Shared timestamp update patterns.

Core timestamps are timestamps that are updated each time, and only when, the user action is executed.

Supporting timestamps are timestamps that are updated sometimes, and only when, the user action is executed.

Shared timestamps are timestamps that are shared between multiple user actions. So, for example, the timestamps of a single file might be updated by two different user actions. With shared timestamps it is impossible to determine which action updated the timestamp without more information.

By categorizing timestamps into these three primary categories, we can construct timestamp signatures to detect if and when a user action must have happened. For example, since only one action can update Core timestamps, the time value of the timestamp is approximately the time in which the user action must have taken place.

The same can be said for Supporting timestamps, but we would expect Supporting timestamps values to be at or before the last instance of the user action.

Using this categorization system, and finding associations of timestamps to user actions, user actions in the past can be reconstructed just by using readily available meta-data in a computer system.

For more information, please see our article on this topic:

James, J., P. Gladyshev, and Y. Zhu. (2011) "Signature Based Detection of User Events for Post-Mortem Forensic Analysis". Digital Forensics and Cyber Crime: Lecture Notes of the Institute for Computer Sciences, Social Informatics and Telecommunications Engineering. Volume 53, pp 96-109. Springer. [PDF][arXiv:1302.2395]
